AMD Ryzen 5 7600X
AMD Ryzen 5 7600X Specifications and Performance Analysis
The AMD Ryzen 5 7600X is based on the Raphael architecture and is manufactured using the 5 nm process at the TSMC foundry. It is compatible with the AM5 socket used by X670E, X670, B650E, B650 chipsets and supports PCIe Gen 5, 24 Lanes (CPU only), as well as DDR5 memory with speeds of up to 5200 MT/s across Dual-channel memory. This processor features 6 cores operating at a base clock of 4.70 GHz and a boost clock of up to 5.30 GHz, for a total of 12 threads. It is equipped with 64 kB of L1 cache, 1024 kB of L2 cache, and 32 MB of L3 cache.
This CPU is designed for a mainstream desktop platform. It supports consumer-grade memory configurations and modern expansion standards, making it suitable for everyday computing, gaming, and productivity workloads.The AMD Ryzen 5 7600X has a base TDP of 105 W and a moderate maximum TDP of 142 W. Most mid-range aftermarket air coolers are sufficient for thermal control. This processor is also suitable for small form factor builds, which often have limited airflow.
For users who require integrated graphics, this CPU includes the Radeon Graphics, which features 2 GPU cores. It operates at a base clock of 400.00 GHz and boosts up to 2200.00 GHz. This makes it suitable for systems without a dedicated GPU, capable of handling everyday tasks and running older or less demanding games. Integrated graphics can also accelerate specific workloads even when a discrete GPU is installed.
Application Performance
AMD Ryzen 5 7600X is an entry-level CPU, achieving a relative application performance score of 39.70% of the best possible desktop CPU performance. This CPU handles daily computing, coding, light gaming, productivity, and basic multitasking. Not recommended for heavy workloads or professional-grade applications.
In terms of productivity value, AMD Ryzen 5 7600X offers excellent performance per dollar, achieving 78.4% efficiency relative to the best possible CPU in the application performance-per-price category. It is an excellent choice for cost-effective computing.
Gaming Performance
AMD Ryzen 5 7600X is a mid-range gaming CPU, achieving a relative gaming performance score at 1080p resolution of 76.78% compared to the best possible desktop CPU gaming performance. This CPU provides solid mid-level gaming, performance and is best paired with corresponding mid-range graphics cards. Note that CPU-related performance limitations decrease as GPU performance lowers—particularly at higher resolutions—since the GPU becomes the bottleneck.
For gamers, AMD Ryzen 5 7600X offers exceptional value, scoring 87.4% in gaming performance per dollar. It's ideal for budget-conscious gamers looking to pair this CPU with a cost-effective graphics card without significantly sacrificing performance.
General Information
| CPU Name | AMD Ryzen 5 7600X |
|---|---|
| Release Price | $299.00 |
| Current Price on Amazon | $167 |
| Amazon Price Updated | 3 days, 9 hours ago. |
| Launch Date | 3 years, 8 months ago. |
| CPU Available | True |
| Architecture | Raphael |
|---|---|
| Foundry | TSMC |
| Process | 5 nm |
| Socket | AM5 |
| Chipsets | X670E, X670, B650E, B650 |
| Transistors | 6570 million |
| Die Size | 71 mm² |
| PCIe Version | Gen 5, 24 Lanes (CPU only) |
| Cores / Threads | 6 / 12 |
|---|---|
| Base / Boost Clock | 4.70 GHz / 5.30 GHz |
| Memory Support / Max Speed | DDR5 / 5200 MT/s |
|---|---|
| Memory Bandwidth | 83.2 GB/s |
| Memory Channels | Dual-channel |
| ECC Support | True |
| L1 Cache (per core) | 64 kB |
|---|---|
| L2 Cache (per core) | 1024 kB |
| L3 Cache (shared) | 32 MB |
| Base TDP | 105 W |
|---|---|
| Max Turbo Power | 142 W |
| Integrated Graphics | True |
|---|---|
| GPU Name | Radeon Graphics |
| GPU Cores | 2 |
| GPU Base / Boost Clock | 400.00 GHz / 2200.00 GHz |
Cinebench R24 Performance
| Cinebench R24 Multi-core | 885 |
|---|---|
| Cinebench R24 Single-core | 117 |
CPU Normalized Performance Chart
AMD Ryzen 5 7600X Compared to Similar Performance CPUs
CPU Price / Performance Table
| CPU (Desc) | Price (Desc) | Performance (Desc) | Game_Perf (Desc) | Combined (Desc) | Perf/Price (Desc) | Game/Price (Desc) | Combined/Price (Desc) |
|---|---|---|---|---|---|---|---|
|
$337
|
↓
-0.4%
|
43.0%
|
72.7%
|
57.9%
|
42.2%
|
41.0%
|
41.2%
|
|
|
$0
|
0.0%
|
41.0%
|
77.9%
|
59.4%
|
N/A | N/A | N/A | |
|
$159
|
↓
-11.7%
|
40.4%
|
68.3%
|
54.3%
|
83.7%
|
81.6%
|
82.0%
|
|
|
$203
|
↑
13.4%
|
40.4%
|
68.3%
|
54.3%
|
65.6%
|
63.9%
|
64.2%
|
|
|
$167
|
↓
-4.6%
|
39.7%
|
76.8%
|
58.2%
|
78.4%
|
87.4%
|
83.7%
|
|
|
$417❗
|
↓
-38.2%
|
39.4%
|
76.2%
|
57.8%
|
31.2%
|
34.7%
|
33.3%
|
|
|
$228
|
0.0%
|
39.2%
|
63.4%
|
51.3%
|
56.8%
|
52.9%
|
54.1%
|
|
|
$219
|
0.0%
|
39.2%
|
63.4%
|
51.3%
|
59.1%
|
55.1%
|
56.3%
|
|
|
$240
|
0.0%
|
38.8%
|
86.0%
|
62.4%
|
53.4%
|
68.1%
|
62.4%
|
Processor Comparison and Detail Specifications Table
| Specification |
No image available |
Perf Chart | |||||||
|---|---|---|---|---|---|---|---|---|---|
| Price |
$337
|
↓
-0.4%
|
$0
|
0.0%
|
$159
|
↓
-11.7%
|
$203
|
↑
13.4%
|
$167
|
↓
-4.6%
|
$417❗
|
↓
-38.2%
|
$228
|
0.0%
|
$219
|
0.0%
|
$240
|
0.0%
|
| Manufacturer | Intel | AMD | Intel | Intel | AMD | AMD | AMD | AMD | AMD |
| C/SC/T | 12 / 4 / 20 | 6 / 0 / 12 | 10 / 4 / 16 | 10 / 4 / 16 | 6 / 0 / 12 | 8 / 0 / 16 | 8 / 0 / 16 | 8 / 0 / 16 | 6 / 0 / 12 |
| L2 / L3 Cache | 1280.0 kB / 25.0 MB | 1024.0 kB / 32.0 MB | 1280.0 kB / 20.0 MB | 1280.0 kB / 20.0 MB | 1024.0 kB / 32.0 MB | 512.0 kB / 96.0 MB | 512.0 kB / 32.0 MB | 512.0 kB / 32.0 MB | 1024.0 kB / 96.0 MB |
| Base / Boost | 2.10 GHz / 4.90 GHz | 3.80 GHz / 5.00 GHz | 3.70 GHz / 4.90 GHz | 3.70 GHz / 4.90 GHz | 4.70 GHz / 5.30 GHz | 3.40 GHz / 4.50 GHz | 3.80 GHz / 4.80 GHz | 3.80 GHz / 4.70 GHz | 4.10 GHz / 4.70 GHz |
| Memory | DDR4, DDR5 / 4800 MT/s | DDR5 / 5600 MT/s | DDR4, DDR5 / 4800 MT/s | DDR4, DDR5 / 4800 MT/s | DDR5 / 5200 MT/s | DDR4 / 3200 MT/s | DDR4 / 3200 MT/s | DDR4 / 3200 MT/s | DDR5 / 5200 MT/s |
| Arch / Node | Alder Lake-S / 10 nm | Granite Ridge / 4 nm | Alder Lake-S / 10 nm | Alder Lake-S / 10 nm | Raphael / 5 nm | Vermeer / 7 nm | Vermeer / 7 nm | Vermeer / 7 nm | Raphael / 5 nm |
| TDP / Max | 65 W / 180 W | 65 W / 88 W | 125 W / 150 W | 125 W / 150 W | 105 W / 142 W | 105 W / 142 W | 105 W / 142 W | 105 W / 142 W | 65 W / 88 W |
| Socket | LGA 1700 | AM5 | LGA 1700 | LGA 1700 | AM5 | AM4 | AM4 | AM4 | AM5 |
| Int. GPU | None | None | None | UHD Graphics 770 | Radeon Graphics | None | None | None | Radeon Graphics |
CPU Performance in Rendering, Encoding and Compression-Decompression
| CPU (Desc) | CB24_MC (Desc) | CB24_SC (Desc) | CB24_rel (Desc) | Blender (Desc) | Encoding_AV1 (Desc) | Encoding_h265 (Desc) | 7-zip_Pack (Desc) | 7-zip_Unpack (Desc) | Performance (Desc) |
|---|---|---|---|---|---|---|---|---|---|
| 1004 | 110 |
39.7%
|
38.5%
|
51.1%
|
51.0%
|
44.6%
|
33.3%
|
43.0%
|
|
| 870 | 115 |
34.4%
|
34.9%
|
55.3%
|
43.9%
|
41.8%
|
35.7%
|
41.0%
|
|
| 966 | 109 |
38.2%
|
34.0%
|
52.2%
|
43.7%
|
41.4%
|
32.7%
|
40.4%
|
|
| 966 | 109 |
38.2%
|
34.0%
|
52.2%
|
43.7%
|
41.4%
|
32.7%
|
40.4%
|
|
| 885 | 117 |
35.0%
|
28.9%
|
52.3%
|
43.4%
|
42.3%
|
36.4%
|
39.7%
|
|
| 860 | 95 |
34.0%
|
30.4%
|
49.5%
|
39.8%
|
43.2%
|
39.8%
|
39.4%
|
|
| 884 | 97 |
35.0%
|
31.2%
|
48.5%
|
39.0%
|
41.4%
|
40.1%
|
39.2%
|
|
| 884 | 96 |
35.0%
|
31.2%
|
48.4%
|
38.9%
|
41.4%
|
40.1%
|
39.2%
|
|
| 820 | 102 |
32.4%
|
28.5%
|
51.7%
|
42.1%
|
42.7%
|
35.4%
|
38.8%
|
