Sapphire Pure AMD Radeon™ RX 9060 XT Gaming OC 16GB at a glance

The Sapphire Pure AMD Radeon™ RX 9060 XT Gaming OC 16GB is a SAPPHIRE retail card of the RX 9060 XT 16GB on RDNA 4.0. It is not marked as a factory-overclocked board ; the GPU’s reference boost is 3130 MHz.

Length is 240 mm and it occupies 2.0 slots (240 x 124 x 46 mm ). Board power is 170 W with 8 pin x 1. Outputs: 2x HDMI 2.1b 1x DisplayPort 2.1a. Warranty is 36 months.

This is a short card and is a better candidate for compact cases than most RX 9060 XT 16GB partners.

Best fit: Compact builds that need this GPU in a shorter board design, subject to slot-width clearance.

Inherited GPU performance

Raster scores come from the RX 9060 XT 16GB, not from this cooler. At 1440p that is 35.98% of the dataset’s best (entry-level), with 43% at 1080p and 30% at 4K. The chip uses 16 GB GDDR6.

This card’s 1440p value is 40.3 performance per dollar. Other RX 9060 XT 16GB partners in the card table may be cheaper for the same silicon.

Compare other SAPPHIRE and partner boards of this GPU in the RX 9060 XT 16GB retail-card table.
