GIGABYTE GeForce RTX 5060 Ti WINDFORCE OC 8G

Written analysis

GIGABYTE GeForce RTX 5060 Ti WINDFORCE OC 8G at a glance

The GIGABYTE GeForce RTX 5060 Ti WINDFORCE OC 8G is a GIGABYTE retail card of the RTX 5060 Ti 8GB on Blackwell 2.0. It is not marked as a factory-overclocked board ; the GPU’s reference boost is 2572 MHz.

Length is 208 mm and it occupies 2.0 slots (L=208 W=120 H=40 mm). Board power is 180 W with 1 x 8-pin. Outputs: DisplayPort 2.1b (x3), HDMI 2.1b. Warranty is 36 months.

This is a short card and is a better candidate for compact cases than most RTX 5060 Ti 8GB partners.

Best fit: Compact builds that need this GPU in a shorter board design, subject to slot-width clearance.

Inherited GPU performance

Raster scores come from the RTX 5060 Ti 8GB, not from this cooler. At 1440p that is 36.59% of the dataset’s best (entry-level), with 45% at 1080p and 26% at 4K. The chip uses 8 GB GDDR7.

This card’s 1440p value is excellent at 71.0 performance per dollar.

Compare other GIGABYTE and partner boards of this GPU in the RTX 5060 Ti 8GB retail-card table.
