XFX · RX 9060 XT 8GB · 270 mm

XFX Swift AMD Radeon RX 9060 XT OC White

8 GB GDDR6 · 270 mm · 2.5 slots · 150 W

1440p
33%
Value
86
Length
270 mm
Amazon
$380
$380
Unavailable Updated 1 month, 1 week ago Prime FBA
Gaming 1080p40.9%
Gaming 1440p33.2%
Gaming 4K25.5%
1440p value86.4

Written analysis

XFX Swift AMD Radeon RX 9060 XT OC White at a glance

The XFX Swift AMD Radeon RX 9060 XT OC White is a XFX retail card of the RX 9060 XT 8GB on RDNA 4.0. It is not marked as a factory-overclocked board ; the GPU’s reference boost is 3130 MHz.

Length is 270 mm and it occupies 2.5 slots (27 x 12.4 x 4.8 cm). Board power is 150 W with 8 pin x 1. Outputs: DisplayPort 2.1: 2x, ‍ HDMI™ 2.1: 1x. Warranty is 36 months.

Length is mainstream. It fits most ATX cases and many compact mid-towers.

Best fit: Builds prioritizing this card’s price, cooler, output selection, and warranty over a factory overclock.

Inherited GPU performance

Raster scores come from the RX 9060 XT 8GB, not from this cooler. At 1440p that is 33.17% of the dataset’s best (budget), with 41% at 1080p and 26% at 4K. The chip uses 8 GB GDDR6.

This card’s 1440p value is excellent at 86.4 performance per dollar.

Compare other XFX and partner boards of this GPU in the RX 9060 XT 8GB retail-card table.

Board hardware

Full specifications

Partner-card clocks, physical fit, cooling, power delivery, display outputs, and the underlying GPU in one technical sheet.

Identity

Card
XFX Swift AMD Radeon RX 9060 XT OC White
Manufacturer
XFX
Model
XFX Swift AMD Radeon RX 9060 XT OC White
Alt model
Swift AMD Radeon RX 9060 XT OC White
Launch price
Amazon price
$380
Availability
Unavailable
Price updated
1 month, 1 week ago

Fit

Length
270 mm
Slot size
2.5 slots
Dimensions
27 x 12.4 x 4.8 cm
Cooler
Warranty
36 months

Power & I/O

Board power
150 W
Connectors
8 pin x 1
Display outputs
DisplayPort 2.1: 2x, ‍ HDMI™ 2.1: 1x
Factory OC
No

Boost clock vs RX 9060 XT 8GB

Reference GPU boost compared with this partner card. If no partner boost is recorded, the card is shown as using the reference clock.

Boost clock
Reference GPU 3130 MHz
This card 3320 MHz
Delta +190 MHz (6.1%)

GPU silicon

Architecture
RDNA 4.0
Process
4
Interface
PCIe 5.0 x16
VRAM
8 GB GDDR6
Bus / bandwidth
128-bit · 322 GB/s
Shaders / CU-SM
2048 / 32
RT cores
32
Tensor / matrix
64
Reference TDP
150 W
Reference base / boost
1700 MHz / 3130 MHz

Amazon

Price history

Nearby cards

Similar graphics cards

Other retail boards of RX 9060 XT 8GB, plus nearby silicon if the family is small. Price, length, and value are what actually change between partner cards.
