RX 9060 XT 8GB
RX 9060 XT 8GB Review & Specifications
The RX 9060 XT 8GB is based on the RDNA 4.0 architecture and manufactured using the 4 nm process node. It was launched approximately 1 year ago, originally priced at $299. It features 2048 cores, including 32 compute units (SMs), 128 texture mapping units (TMUs), and 64 render output units (ROPs). For ray tracing and AI-accelerated tasks, it also includes 32 dedicated RT cores and 64 Tensor cores, enabling advanced rendering and upscaling features where supported. It has a base clock of 1700 MHz and a boost clock reaching up to 3130 MHz. The RX 9060 XT 8GB comes equipped with 8 GB of GDDR6 memory across a 128-bit bus. Memory runs at 2518 MHz and delivers a total memory bandwidth of 322 GB/s.
This GPU has a low thermal design power (TDP) of 150 W. It is generally compatible with almost all PC cases and is excellent for SFF and compact systems where heat dissipation is a concern.
RX 9060 XT 8GB Performance
RX 9060 XT 8GB is a mid-range graphics card, scoring 40.92% in relative gaming performance. However, the limited 8 GB of VRAM may lead to severe memory bottlenecks at 4K, even with DLSS or FSR. It’s best suited for high FPS in 1080p or smooth 1440p performance, but not recommended for demanding 4K gaming.
The RX 9060 XT 8GB pairs a relatively powerful GPU core with a moderate VRAM size of 8 GB — a configuration that's becoming increasingly common. However, this pairing has sparked significant discussion in the gaming and tech review communities. Many modern GPUs with strong processing capabilities are equipped with insufficient VRAM (often less than 16 GB), which prevents them from realizing their full potential. As a result, GPUs like this one often deliver excellent performance in 1080p gaming at ultra settings, and perform well at 1440p in many titles. However, as modern games demand more VRAM — particularly due to high-resolution textures, ray tracing, and expansive open worlds — this limited memory becomes a bottleneck. In 4K gaming, performance can drop significantly due to VRAM exhaustion, leading to underutilization of the GPU core itself. AMD’s FSR upscaling can help maintain frame rates at higher resolutions, but unlike DLSS, it is not AI-driven and does not leverage hardware acceleration. This GPU configuration still handles basic to intermediate content creation tasks well — such as 1080p/1440p video editing, lightweight 3D modeling, and digital art workflows. In AI and machine learning applications, AMD GPUs have traditionally been limited due to the lack of CUDA and weaker ecosystem integration. However, recent progress through ROCm (Radeon Open Compute) has brought partial support for frameworks like PyTorch and TensorFlow, particularly on Linux. While compatibility can vary and performance remains behind NVIDIA, this GPU may still be usable for lightweight inference or experimentation with supported models.
In terms of gaming value, RX 9060 XT 8GB provides excellent performance per dollar, reaching 80.6% efficiency relative to the best in this category. It performs well in 1080p and 1440p, but due to the limited VRAM, it may struggle with future games or long-term use.
General Information
| GPU Name | RX 9060 XT 8GB |
|---|---|
| GPU Code Name | Navi 44 |
| Release Price | $299 |
| Selected Model | XFX Swift AMD Radeon RX 9060 XT 8GB OC |
| Current Price Amazon | $370 |
| Amazon Price Updated | 10 hours, 17 minutes ago |
| Launch Date | 1 year ago |
| GPU Available | True |
| Architecture | RDNA 4.0 |
|---|---|
| Foundry | TSMC |
| Process | 4 |
| Transistors | 29700 million |
| Die Size | 199 mm² |
| Bus Interface | PCIe 5.0 x16 |
| TDP | 150 W |
| Cores | 2048 |
|---|---|
| CUs (SMs) | 32 |
| TMUs | 128 |
| ROPs | 64 |
| RT Cores | 32 |
| Tensor Cores | 64 |
| L0 Cache | 32 KB per WGP |
| L2 Cache | 4 MB |
| L3 Cache | 32 MB |
| Base Clock | 1700 MHz |
|---|---|
| Boost Clock | 3130 MHz |
| Memory Size - Type | 8 GB GDDR6 |
|---|---|
| Memory Bus Width | 128 bit |
| Memory Clock | 2518 MHz |
| Memory Bandwidth | 322 GB/s |
| DirectX | 12 Ultimate (12_2) |
|---|---|
| OpenGL | 4.6 |
| OpenCL | 2.2 |
| Vulkan | 1.4 |
| Shader Model | 6.8 |
Theoretical Performance
| Pixel Rate | 200.30 GPixel/s |
|---|---|
| Texture Rate | 400.60 GTexel/s |
| FP16 | 51.28 TFLOPS |
| FP32 | 25.64 TFLOPS |
| FP64 | 801.30 GFLOPS |
Gaming Performance Chart
RX 9060 XT 8GB Compared to Similar Performance GPUs
GPU Price / Performance Table
| GPU (Desc) | Price (Desc) | Gaming_1080p (Desc) | Gaming_1440p (Desc) | Gaming_2160p (Desc) | Game_1440p/Price (Desc) |
|---|---|---|---|---|---|
|
$400
|
0.0%
|
44.6%
|
36.6%
|
25.7%
|
82.2%
|
|
|
$470
|
↓
-6.0%
|
42.8%
|
36.0%
|
29.9%
|
68.8%
|
|
|
$385
|
↓
-14.5%
|
42.5%
|
35.7%
|
30.6%
|
83.4%
|
|
|
$335
|
↑
1.5%
|
40.3%
|
33.8%
|
28.5%
|
90.7%
|
|
|
$370
|
↑
5.7%
|
40.9%
|
33.2%
|
25.5%
|
80.6%
|
|
|
$370
|
↓
-14.0%
|
38.8%
|
32.8%
|
28.7%
|
79.7%
|
|
|
$675
|
0.0%
|
39.1%
|
32.6%
|
26.5%
|
43.4%
|
|
|
$345
|
0.0%
|
39.1%
|
31.7%
|
24.3%
|
82.6%
|
|
|
$557❗
|
↑
0.9%
|
38.5%
|
31.7%
|
25.7%
|
51.2%
|
GPU Specification Table
| GPU (Desc) | Architecture | Shader/TMU/ROP/RT | Base/Boost Clock | Memory | Mem Clock/Bandwidth | TDP |
|---|---|---|---|---|---|---|
| RTX 5060 Ti 8GB | GB206 / 5 nm nm / Blackwell 2.0 | 4608 / 144 / 48 / 36 | 2407 MHz / 2572 MHz | 8 GB GDDR7 / 128 bit | 1750 MHz / 448 GB/s | 180 W |
| RX 9060 XT 16GB | Navi 44 / 4 nm / RDNA 4.0 | 2048 / 128 / 64 / 32 | 1700 MHz / 3130 MHz | 16 GB GDDR6 / 128 bit | 2518 MHz / 322 GB/s | 160 W |
| RTX 3070 Ti | GA104 / 8 nm nm / Ampere | 6144 / 192 / 96 / 48 | 1575 MHz / 1770 MHz | 8 GB GDDR6X / 256 bit | 1188 MHz / 608 GB/s | 290 W |
| RTX 3070 | GA104 / 8 nm nm / Ampere | 5888 / 184 / 96 / 46 | 1500 MHz / 1725 MHz | 8 GB GDDR6 / 256 bit | 1750 MHz / 448 GB/s | 220 W |
| RX 9060 XT 8GB | Navi 44 / 4 nm / RDNA 4.0 | 2048 / 128 / 64 / 32 | 1700 MHz / 3130 MHz | 8 GB GDDR6 / 128 bit | 2518 MHz / 322 GB/s | 150 W |
| RTX 2080 Ti | TU102 / 12 nm nm / Turing | 4352 / 272 / 88 / 68 | 1350 MHz / 1545 MHz | 11 GB GDDR6 / 352 bit | 1750 MHz / 616 GB/s | 250 W |
| RTX 4060 Ti 16GB | AD106 / 5 nm nm / Ada Lovelace | 4352 / 136 / 48 / 34 | 2310 MHz / 2535 MHz | 16 GB GDDR6 / 128 bit | 2250 MHz / 288 GB/s | 165 W |
| RTX 4060 Ti 8GB | AD106 / 5 nm nm / Ada Lovelace | 4352 / 136 / 48 / 34 | 2310 MHz / 2535 MHz | 8 GB GDDR6 / 128 bit | 2250 MHz / 288 GB/s | 160 W |
| RX 6750 XT | Navi 22 / 7 nm / RDNA 2.0 | 2560 / 160 / 64 / 40 | 2150 MHz / 2600 MHz | 12 GB GDDR6 / 192 bit | 2250 MHz / 432 GB/s | 250 W |
Graphics Cards Based on the RX 9060 XT 8GB GPU
| Specification | Perf Chart | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Price |
$580
|
↑
30.9%
|
$395
|
↓
-9.6%
|
$370❗
|
↑
5.7%
|
$490
|
0.0%
|
$360❗
|
0.0%
|
$420
|
0.0%
|
$389❗
|
↑
2.6%
|
$313❗
|
↑
1.7%
|
$530
|
0.0%
|
| GPU | AMD RX 9060 XT 8GB | AMD RX 9060 XT 8GB | AMD RX 9060 XT 8GB | AMD RX 9060 XT 8GB | AMD RX 9060 XT 8GB | AMD RX 9060 XT 8GB | AMD RX 9060 XT 8GB | AMD RX 9060 XT 8GB | AMD RX 9060 XT 8GB |
| Manufacturer | ASUS | Sapphire Technology | XFX | XFX | GIGABYTE | ASUS | PowerColor | PowerColor | ASRock |
| Chip/Process/Arch | Navi 44 / 4 nm / RDNA 4.0 | Navi 44 / 4 nm / RDNA 4.0 | Navi 44 / 4 nm / RDNA 4.0 | Navi 44 / 4 nm / RDNA 4.0 | Navi 44 / 4 nm / RDNA 4.0 | Navi 44 / 4 nm / RDNA 4.0 | Navi 44 / 4 nm / RDNA 4.0 | Navi 44 / 4 nm / RDNA 4.0 | Navi 44 / 4 nm / RDNA 4.0 |
| Cores/TMU/ROP/RT | 2048 / 128 / 64 / 32 | 2048 / 128 / 64 / 32 | 2048 / 128 / 64 / 32 | 2048 / 128 / 64 / 32 | 2048 / 128 / 64 / 32 | 2048 / 128 / 64 / 32 | 2048 / 128 / 64 / 32 | 2048 / 128 / 64 / 32 | 2048 / 128 / 64 / 32 |
| Base/Boost MHz | 1700 MHz / 3130 MHz | 1700 MHz / 3130 MHz | 1700 MHz / 3130 MHz | 1700 MHz / 3130 MHz | 1700 MHz / 3130 MHz | 1700 MHz / 3130 MHz | 1700 MHz / 3130 MHz | 1700 MHz / 3130 MHz | 1700 MHz / 3130 MHz |
| Factory OC MHz | 3130 MHz | 3290 MHz | 3320 MHz | 3320 MHz | 3320 MHz | 3330 MHz | 3310 MHz | 3230 MHz | 3290 MHz |
| VRAM / Bus | 8 GB GDDR6 / 128 bit | 8 GB GDDR6 / 128 bit | 8 GB GDDR6 / 128 bit | 8 GB GDDR6 / 128 bit | 8 GB GDDR6 / 128 bit | 8 GB GDDR6 / 128 bit | 8 GB GDDR6 / 128 bit | 8 GB GDDR6 / 128 bit | 8 GB GDDR6 / 128 bit |
| Mem Clock/Band | 2518 MHz / 322 GB/s | 2518 MHz / 322 GB/s | 2518 MHz / 322 GB/s | 2518 MHz / 322 GB/s | 2518 MHz / 322 GB/s | 2518 MHz / 322 GB/s | 2518 MHz / 322 GB/s | 2518 MHz / 322 GB/s | 2518 MHz / 322 GB/s |
| TDP | 150 W | 150 W | 150 W | 150 W | 150 W | 150 W | 150 W | 150 W | 150 W |
| Power Connector | 8 pin x 1 | 8 pin x 1 | 8 pin x 1 | 8 pin x 1 | 8 pin x 1 | 8 pin x 1 | 8 pin x 1 | 8 pin x 1 | 8 pin x 1 |
| Dimensions | 202 x 120 x 49mm | 240(L)X 124(W)X 46.1 | 27 x 12.4 x 4.8 cm | 27 x 12.4 x 4.8 cm | L=281 W=118 H=40 mm | 304 x 126 x 50mm | 330mm*120mm*40mm | 220mm*120mm*40mm | 249 x 132 x 41 mm |
