ASRock Radeon RX 9060 XT Challenger 16GB

Written analysis

ASRock Radeon RX 9060 XT Challenger 16GB at a glance

The ASRock Radeon RX 9060 XT Challenger 16GB is a ASRock retail card of the RX 9060 XT 16GB on RDNA 4.0. It is not marked as a factory-overclocked board ; the GPU’s reference boost is 3130 MHz.

Length is 249 mm and it occupies 2.0 slots (249 x 132 x 41 mm). Board power is 160 W with 8 pin x 1. Outputs: - 2x DisplayPort 2.1a - 1x HDMI 2.1b. Warranty is 36 months.

This is a short card and is a better candidate for compact cases than most RX 9060 XT 16GB partners.

Best fit: Compact builds that need this GPU in a shorter board design, subject to slot-width clearance.

Inherited GPU performance

Raster scores come from the RX 9060 XT 16GB, not from this cooler. At 1440p that is 35.98% of the dataset’s best (entry-level), with 43% at 1080p and 30% at 4K. The chip uses 16 GB GDDR6.

This card’s 1440p value is balanced at 68.5 performance per dollar.

Compare other ASRock and partner boards of this GPU in the RX 9060 XT 16GB retail-card table.
